The DZR15 is a 2-way bi-amped powered loudspeaker that offers superb clarity at an impressive maximum SPL of 139dB. With best-in-class SPL performance, sophisticated DSP processing, and unrivaled low-frequency sound reproduction, the DZR15 realizes a truly professional sound delivered with a level of power that belies its compact, lightweight design.
DZR15 | ||
---|---|---|
Speaker type | 2-way, Bi-amped Powered Speaker, Bass-reflex | |
Frequency range (-10dB) | 34Hz - 20kHz | |
Coverage area | H90゚ x V50゚ (Rotatable) | |
Components | LF | 15" Cone, 3" Voice Coil, Neodymium magnet |
MF | - | |
HF | 2" Voice Coil, 1" Throat Compression Driver, Titanium diaphragm, Neodymium magnet | |
Crossover | 1.7kHz (FIR-X) | |
Sampling frequency rate | Internal | 96kHz and FIR Filter |
A/D D/A Converters | 96kHz AD/DA | |
Maximum output level (1m; on axis) | 139dB SPL *1 | |
Power rating | Dynamic | 2000W (LF: 1000W, MF/HF: 1000W) *2 |
Burst (20ms) | 1100W (LF: 1000W, MF/HF: 100W) | |
Continuous | 950W (LF: 850W, MF/HF: 100W) | |
I/O Connectors | Analog I/O | Analog IN: Combo x2, Line level (Maximum +24dBu), Input impedance 20kΩ, Analog OUT: XLR3-32 x2, CH1: THRU (fix), CH2: THRU or DSP OUT |
Others | USB2.0 Host 5V 500mA for USB memory DATA storage/load | |
AC | IEC AC inlet x1 (V-Lock) | |
Amplifier class | Class-D | |
Cooling | Fan cooling, Variable speeds | |
Power consumption | 45W (Idle), 150W (1/8) | |
Handle | Aluminium die-cast, Side x2 | |
Rigging | M10 x12 | |
Dimensions | W | 450 mm (17.7") |
H | 761 mm (30.0") (with rubber feet) | |
D | 460 mm (18.1") | |
Net weight | 25.2kg (55.6lbs) | |
Options | U-bracket: UB-DZR15H/V, Cover: SPCVR-DZR15 | |
Others | Enclosure Material, Finish, Color: Plywood, Durable Polyurea Painting, Black/White | |
Floor Monitor Angle | 50° Symmetrical | |
Pole socket | Φ35 mm x2 (0° or -7°) |
